Residual Current Monitoring Devices: Solutions for Electric Vehicles, Solar Energy and Industrial Power Leaks in Brazil

Views : 336
Update time : 2026-05-05 12:53:31

1. Why are engineers faced with the problem of current leakage in practical application?



1.1 Errors in the field and not within the project



In Brazilian projects, it often happens that the system works well on paper, but on the site, failures occur that are manifested mainly by:

● Charger for electric vehicles

● Photoelectric system

● Industrial panel

In most cases, the problem lies in the limitations of the measurement system in the absence of an appropriate residual current monitoring device.



2. Annex 1: Charger for electric vehicles



2.1 Why do electric vehicles need more advanced testing?



In the current transformers for EV chargers, the current leak can contain constant current components even at very low levels.

This can lead to:

● Lack of differential protection

● User risk

● Not compliant with IEC 62955



2.2 HYCA - 01 How to solve the problem



HYCA-01 as special residual current control device for electric vehicles:

● Variable current + constant current detection

● typical ignition: 30mA AC/~4.5mA DC

● Digital Output System

 Directly addresses the need for how to detect DC leakage current in EV chargers.



3. Application 2: Photoelectric (solar) systems



3.1 Typical problems in the field



In solar inverter current transformers, leakage current may appear gradually for the following reasons:

● Aging of the cable

● Denial of isolation

● Environmental conditions

Without constant monitoring, these errors will be ignored.



3.2 Solutions for continuous monitoring



Paragraph HYCA-01:

● Constant current output PWM (0 - 30 mA)

● Accuracy ~±0.5mA

 Defect detection before damage or fire



4. Annex 3 : Industrial panels and automation



4.1 Problems in the industrial environment



In industrial systems, power leaks are difficult to recognize because:

● Periodic occurrence

● Traditional current transformers cannot detect



4.2 Benefits in Practice



HYCA-01 as a residual current monitoring device allows:

● Real monitoring

● Diagnostic Error Extraction

● Direct integration with PLC

 Result: fewer failures, fewer parades

 Residual Current Monitoring Device

5. Why replace traditional transformers?



5.1 Limitations to Modern Application



Systems based solely on current transformers:

● No constant current detected

● Electric vehicles and solar energy are not maintained

● Increased operational risk



5.2 Direct Benefits of HYCA-01



Use residual current monitoring devices like HYCA-01:

● Integrated switch + DC control

● Self-control function

● Easy integration (5V / PCB / up to 40A)

 Residual Current Monitoring Device


6. Conclusion: the choice is based on application and not only on components



6.1 The scene has changed.



Nowadays, it is not enough to choose a sensor. The The annex determines the decision.

Residual current monitoring devices are needed for electric vehicles, solar power and industry.



6.2 Next stages of the project



If you are developing:

● current transformer for EV charger

● current transformer for solar inverters

● HYCA-01 offers a direct solution for AC + DC leak current detection.



Request for technical support or proposal
Contact us:

● Data table HYCA-01

● Application support

● Factory Direct Offer

Quick response to the Brazilian project.

Compay: WENZHOU HEYI ELECTRICAL CO.,LTD

Brand: HEYI/ASCT

Contact: Bethy

E-mail: heyi@heyiele.com

Tel: 86-13968747975
