Where Is a Current Transformer Used in South Africa’s LV Electrical Projects?

Views : 200
Update time : 2026-09-14 16:03:19

1. What challenges do engineers face in existing LV electrical systems?



In South African LV projects, engineers often need to add a current transformer to existing panels, kitchens or appliances without rethinking the entire circuit. Limited space and difficult circuit separation can hamper modernization measures. The DP-23 uses a shared core construction that fits wires without circuit breaking.



2. How to use the DP-23 on existing distribution panels?



2.1 Monitoring of major revenues and suppliers



The DP-23 can be installed around input or output cables to monitor current in distribution boards and memories. Available reports include 100/5A, 150/5A, 200/5A, 250/5A, 300/5A and 400/5A.

For a current transformer for electrical panel, its split construction is particularly useful for modernizing existing installations.



2.2 Sub-distribution and load monitoring



Engineers can use the DP-23 on selected plates, to monitor individual electrical loads and identify electricity needs in different circles in buildings and industrial facilities.

 current transformer

3. Where can the DP-23 be used for monitoring factory equipment?



3.1 Engines and air compressors



Factories can install DP-23 on motors and compressors to measure workflow and monitor support devices. The DP series is specially designed for current and power measurement of motors and air compressors.



3.2 HVAC, lighting and automation



The DP-23 can also be used for heating, ventilation, air conditioning, lighting and automation systems.

The current transformer for energy meter can provide a necessary current signal for power monitoring devices, while the DP series for current, performance and power monitoring applications was developed.

 current transformer

4. How to apply DP-23 for LV Busbars?



4.1 Power measurement busbar



For LV wrenches, the DP-23 supports rail mounting and its internal window can accommodate cables or rails. Therefore, the current converter is suitable for current transformer for busbar applications, including monitoring of main tracks and distribution facilities.



4.2 Indicator and choice of installation



The DP-23 includes basic ratios from 100/5A to 400/5A, with options for an internal window of 20 mm and 32 mm. Before installation, engineers must adapt the ratio and size of the aperture to the actual circuit.

 current transformer

5. Why is the DP-23 the practical choice for LV applications?



The DP-23 combines a shared core installation, flexible mounting and a variety of ratios for LV distribution boards, memories, motors, CVC, Energieüberwachung und Balkenanwendungen. For engineers looking for a split core current transformer, it offers a practical option for existing electrical systems.

Need the good DP-23 ratio for your project? Contact HEYI ELECTRICAL for technical selection and price.

Compay: WENZHOU HEYI ELECTRICAL CO.,LTD

Brand: HEYI/ASCT

Contact: Bethy

E-mail: heyi@heyiele.com

Tel: 86-13968747975
